CAD / CAM / CAE
-
CAD / CAM SOFTWARE
AUTO CAD CATIA UG NX POWER SHAPE POWER MILL UG NX MANUFACTURING -
CAE SOFTWARE
LS DYNA ABAQUS NASTRAN MAGMA
PROGRAM & USAGE
| PROGRAM | USAGE |
|---|---|
| AUTOCAD | Products Design and Mould Design |
| CATIA UG NX |
Product 3D Modeling |
| POWERSHAPE | Mould 3D Modeling |
| POWERMILL UG NX MANUFACTURING |
CAM(Computer aided manufacturing) |
| LS-DYNA ABAQUS |
Fatigue test analysis |
| NASTRAN | Solidification Simulation |
| MAGMA | Stiffness analysis |
IMPACT SIMULATION
PLAY VIDEO
RADIAL FATIGUE SIMULATION
ROTARY FATIGUE SIMULATION
FILLING & SOLIDIFICATION SIMULATION
PLAY VIDEO
RIM DEFORMATION ANALYSIS
RESONANCE DURABILITY ANALYSIS
PLAY VIDEO
